Customized Shape Precision Optical Glass Flats and Substrates

An optical glass plate (or sheet) is a high-precision material manufactured from specially formulated glass to possess specific and consistent properties for manipulating light. Its primary function is to transmit, reflect, refract, or modify light waves in optical systems with minimal distortion or energy loss.

Unlike ordinary window glass, optical glass is characterized by its exceptional homogeneity, purity, and precisely controlled optical constants.

Key Characteristics:

• Precise Refractive Index

The refractive index is a fundamental property, meticulously controlled during manufacturing for each glass type. It determines how severely the glass bends light.

• Precise Abbe Number

Also known as the constringence, this measures the material's dispersion (its tendency to separate light into its constituent colors, like a prism). A high Abbe number indicates low dispersion, which is critical for reducing chromatic aberration in lenses.

• High Homogeneity

The refractive index is consistent throughout the entire volume of the glass plate. There are no striae, bubbles, or inclusions that could distort the light wavefront.

• Excellent Transmission

Designed to have very high transmittance across specific wavelength ranges (e.g., visible, UV, or IR), with minimal absorption and scatter.

• Superior Surface Quality

Surfaces are ground and polished to extreme flatness and smoothness. Quality is often specified by scratch-dig standards and surface flatness measured in wavelengths of light

• Specific Mechanical & Thermal Properties

Properties like hardness, density, and coefficient of thermal expansion are carefully considered for the intended application to ensure stability and durability.

Common Types of Optical Glass

• Crown Glass:

Generally has a lower refractive index and a high Abbe number (low dispersion). Used for elements where controlling chromatic aberration is key.

• Flint Glass:

Contains lead or other heavy metals, giving it a higher refractive index and a lower Abbe number (high dispersion). Often used in combination with crown glass to correct for chromatic aberration.

Primary Applications:

Optical glass plates are fundamental components in a vast array of devices and systems:

• Lenses and Objectives: For cameras, microscopes, telescopes, binoculars, and projectors.
• Prisms: Used to bend, rotate, or split light beams (e.g., in binoculars, spectrometers).
• Windows and Protective Covers: On instruments, sensors, and lasers where a clear, undistorted view is necessary.
• Beamsplitters: Plates that divide a beam of light into two separate paths.
• Filters: Substrates for coated filters that selectively transmit or block specific wavelengths.
• Substrates: For mirrors, diffraction gratings, and other optical coatings.

Key Advantages of the optical glass

The primary advantages of optical glass plates are their precision, consistency, and versatility.

They are the fundamental building blocks for creating high-performance optical systems where control over light is paramount, from simple camera lenses to complex microscopes and lithography machines.

• Precise and Predictable Optical Properties:

Controlled Refractive Index: Each type of optical glass has a precisely defined refractive index, allowing designers to accurately calculate light paths in lenses and prisms.

Managed Dispersion (Abbe Number): The Abbe number is carefully specified, enabling the correction of chromatic aberration (color fringing) in multi-element optical systems.

• Excellent Transmission:

High Transmittance:They are formulated for maximum light transmission with minimal absorption loss across specific spectral ranges (UV, Visible, or IR).

Low Scatter and Inclusions:High homogeneity ensures that light passes through without being scattered or distorted by internal imperfections, preserving image quality.

• Superior Surface Quality and Flatness

Surfaces can be polished to extreme smoothness and flatness (e.g., λ/10 flatness, 10-5 scratch-dig), which is critical for applications like laser windows, interferometry, and precise mirrors where any surface defect would degrade performance.

• High Homogeneity

The chemical composition and refractive index are uniform throughout the entire volume of the glass. This eliminates internal distortions and ensures consistent optical performance across the entire aperture.

• Excellent Environmental and Chemical Stability

Many optical glasses are designed to be highly resistant to staining, weathering, and moisture, ensuring long-term durability and stable performance in harsh environments.

• Customizability and Variety

A wide range of glass types is available (e.g., Crown, Flint, Fused Silica) with different properties (refractive index, Abbe number, density) to meet the exact requirements of virtually any optical system design.

• Good Mechanical Rigidity

Compared to plastics, optical glass offers greater hardness and rigidity, providing better resistance to scratching and maintaining its shape under stress, which is vital for preserving optical alignment.

Technical specifications
