Porous ceramic wicks for electric mosquito liquid repellent

Porous ceramic wicks for electric mosquito liquid repellent

Main Component:

Alumina, content up to 80%–95%

Porosity:

60%–75% with large specific surface area, strong adsorption capacity

Filtration Accuracy:

Precise interception of tiny particles down to 1-3 μm

Key Properties:

Chemically inert, acid and alkali resistant, non-toxic and biodegradable

Processing Type:

Natural type and 600–1000℃ calcined type

Core Application:

Widely used in matching core accessories of household electric mosquito liquid heaters, suitable for bedroom, living room, study and other family indoor mosquito repellent scenarios. Stable volatilization performance ensures long-term and efficient mosquito repellent effect for family living spaces.

Introduction

Product Details

1. Overview of Porous Ceramic Wick

1.1 Definition of ceramic mosquito liquid wick

The microporous ceramic mosquito liquid wick rod is a core functional ceramic accessory specially developed for electric mosquito liquid diffusers, indoor aromatherapy devices and liquid volatilization equipment. Manufactured from high-purity ceramic raw materials through high-temperature sintering and precise pore-forming technology, this cylindrical ceramic rod features a uniform three-dimensional microporous structure inside the body. Different from traditional cotton wicks and fiber wicks that are prone to aging and clogging, ceramic wick rods adopt rigid integral molding, with stable physical and chemical properties, realizing continuous, uniform and stable liquid absorption and volatilization. The product serves as the key medium for guiding mosquito liquid and aromatherapy essential oil, ensuring consistent volatilization efficiency during long-term equipment operation, which effectively improves the service stability of electric mosquito repellent devices.

1.2 Standard Product Specifications

Our standard microporous ceramic wick rod comes with conventional dimensions of 7mm in diameter and 73mm in length, which perfectly matches most mainstream electric mosquito liquid heaters and household aromatherapy machines on the market. The product adopts standardized industrial production with consistent pore density and uniform pore size distribution, ensuring stable liquid permeability. All products are inspected in strict accordance with industrial standards, with stable water absorption and liquid guiding performance, no liquid leakage, no rapid liquid overflow, and no intermittent volatilization. In addition to standard sizes, we support full-size customized production according to customer drawings, samples and equipment installation requirements, including personalized adjustment of diameter, length, roundness and end face flatness to adapt to different types of volatilization equipment.

1.3 Production Technology Description

This ceramic wick rod is made by batching high-purity ceramic powder, uniform mixing, extrusion molding, low-temperature drying and high-temperature sintering. The integral molding process avoids structural separation and internal defects. The precise post-processing technology ensures smooth rod surface, neat end faces and no burrs. The internal microporous structure is formed naturally during sintering without chemical pore-forming agents, featuring safe and environmentally friendly performance. The whole production process is controllable, with high product consistency, which can meet the mass matching demand of civil and commercial mosquito repellent and aromatherapy equipment.

2. Product Core Features

2.1 Stable Microporous Liquid Conduction Structure

The interior of the ceramic wick rod is equipped with uniformly distributed interconnected micropores, which form a perfect capillary liquid conduction system. This structure can automatically absorb and transport mosquito liquid and essential oil evenly, realizing slow and continuous volatilization. It effectively solves the common problems of traditional cotton wicks such as uneven liquid absorption, local blockage, reduced volatilization after long-term use, and greatly optimizes the continuous working performance of the equipment.

2.2 Excellent High Temperature & Aging Resistance

Made of high-temperature sintered ceramic material, the wick rod has stable high-temperature resistance, no softening, deformation or carbonization under long-term heating working conditions. Different from fiber and cotton wicks which are easy to age, harden and blacken after heating, the ceramic wick rod maintains stable structural and functional performance during long-cycle use, with no aging failure, significantly extending the service life of consumable accessories.

2.3 Uniform & Durable Volatilization Effect

Relying on the orderly microporous capillary principle, the product realizes quantitative liquid guide and constant volatilization. The volatilization amount will not fluctuate greatly due to the change of liquid level, avoiding excessive volatilization in the early stage and insufficient volatilization in the later stage. It maintains a balanced mosquito repellent and aromatherapy effect in the whole service cycle, with stable and reliable use effect.

2.4 Safe, Eco-friendly & Corrosion Resistant

The ceramic material is non-toxic, tasteless, safe and environmentally friendly, with excellent chemical corrosion resistance. It will not react with mosquito liquid, plant essential oils and other chemical liquids, no precipitation, no peculiar smell. The rigid ceramic structure is not easy to mildew, rot or breed bacteria, ensuring clean and safe indoor use environment.

3. Product Competitive Advantages

3.1 Long Service Life & Low Replacement Cost

Traditional cotton wicks and fiber wicks belong to vulnerable consumables, which are easy to block and fail after a short period of use and need frequent replacement. Our microporous ceramic wick rod features wear resistance, aging resistance and high structural stability. It can be used continuously for a long time without frequent replacement, effectively reducing the after-sales maintenance cost and accessory replacement cost of mosquito repellent and aromatherapy equipment.

3.2 High Compatibility & Strong Versatility

The standard 7*73mm size is highly compatible with most electric mosquito liquid heaters and small aromatherapy volatilizers in the market. Meanwhile, customizable size parameters support matching various special-shaped equipment and new product development. It is suitable for mass supporting of finished product manufacturers and bulk replacement sales of accessory merchants, with extremely high market versatility.

3.3 Stable Performance & Low Defect Rate

Adopting industrial standardized sintering and molding technology, the product has consistent pore size and liquid guiding performance in batches. There is no poor liquid conduction, no sudden stop of volatilization, no liquid leakage and other abnormal problems. The batch stability is far superior to traditional fiber wicks, which can effectively improve the qualified rate of finished equipment and reduce customer complaints and after-sales problems.

3.4 Flexible Customization & Mature OEM Service

On the basis of standard 7*73mm products, we support personalized customization of different diameters, lengths and precision tolerances. We can adjust the pore density and liquid volatilization speed according to customers' requiremnts， helping customers develop differentiated high-quality products.

3.5 Safe & Zero Pollution Use Experience

The whole ceramic body is free of chemical additives, no volatile harmful substances during heating and volatilization, no peculiar smell and no smoke. It conforms to international environmental protection and safety standards for indoor supplies. It provides pure and safe mosquito repellent and aromatherapy effects for family, office and commercial spaces.

4. Main Application Fields

4.1 Household Electric Mosquito Repellent Equipment

Widely used in matching core accessories of household electric mosquito liquid heaters, suitable for bedroom, living room, study and other family indoor mosquito repellent scenarios. Stable volatilization performance ensures long-term and efficient mosquito repellent effect for family living spaces.

4.2 Indoor Aromatherapy Volatilization Equipment

Suitable for small desktop aromatherapy machines, plug-in aromatherapy volatilizers and portable fragrance devices. It can match various water-soluble and oil-soluble essential oils, realizing uniform and lasting indoor fragrance diffusion, applicable to home, office and study space fragrance optimization.

4.3 Commercial Civilian Electronic Accessories

As standard consumable accessories for mass-produced mosquito repellent and aromatherapy electronic products, it supports batch supporting for electronic appliance factories and finished product manufacturers. With stable batch performance, it is the preferred matching accessory for medium and high-end mosquito repellent and aromatherapy equipment.

4.4 Customized Supporting

Our standard size is Dia7*Length73mm. At the same time, customized size and performance services can meet the personalized supporting needs of foreign new product development and brand customized equipment.

4.5 Special Liquid Volatilization Industrial Equipment

After customized adjustment of pore structure and liquid conduction speed, the ceramic wick rod can also be applied to special industrial liquid volatilization, humidification equipment and experimental volatilization devices, with wide industrial expansion and application value.

5. Technical Data

项目

Item

陶土头/渗灌管Infiltration Cup

植物吸水棒

Plant Water

Absorbing Wick

电极砂芯

Electrode Wick

陶瓷芯棒Ceramic Wick

曝气板/管

Aerator plate/tube

香薰陶瓷

Scented Ceramic

真空陶瓷吸盘

Vacumm Ceramic Chunk

废水废气处理微孔陶瓷

Porous Ceramic for water and gas treatment

白色氧化铝

White alumina

碳化硅

Silicon Carbide

密度(g/cm³)

Density

1.6-2.0

0.8-1.2

1.8-2.2

0.8-1.2

2.5-2.6

1.6-2.0

1.7-2.0

2.8-3.2

2.6-3.0

开放孔率(%) Open Porosity

Rate

30-40

50-60

20-30

40-60

30-35

30-45

35-40

气孔率(%) Porosity Rate

40-50

60-75

25-40

60-75

35-36

40-50

40-45

30-40%

吸水率(%)

Water

Absorption

25-40

40-70

10-28

40-70

20-23

25-40

25-35

孔径 ( μm） Pore Size

1-5

1-3

1-5

1-10

2-50um

20-80um

Development History

Patents and certification

We’ve obtained various global certifications including CE, EMC, LVD, RoHS, FDA, MSDS, ISO 9001, SGS and TUV. We also own eight registered trademarks and forty technical patents to support independent R&D.

Our proprietary core technologies run through all product lines: porous ceramics, industrial ceramic components, special glass, metallized ceramics, liquid absorption cotton, ozone generators and silicone goods. All products are manufactured in strict accordance with international quality standards, delivering reliable and high-performance solutions that have gained wide recognition and market trust worldwide.

新建 PPTX 演示文稿_02.png

Package

We adopt scientific and standardized packaging solutions tailored to product characteristics to effectively prevent collision, extrusion, dust and moisture damage. With mature global transportation system and strict shipment inspection procedures, we ensure all products remain intact and stable during long-distance delivery, providing customers with safe, efficient and reliable one-stop logistics service.


Services

Inquiry & Customization

We provide fast and accurate quotation response for all your inquiries. Flexible OEM & ODM customization solutions are available to meet your unique product design, packaging and branding requirements.

Order Quality Control

We keep clients updated with full production progress throughout the whole order cycle. Our QC team carries out strict comprehensive pre-shipment inspection to guarantee all goods comply with your quality standards before delivery.

Customs Document Support

We prepare a full set of standard export documents including commercial invoice, packing list, certificate of origin and other certification papers, to ensure smooth global customs clearance for shipments to all destinations worldwide.

One-Stop Logistics

Multiple shipping methods including sea freight, air freight and express delivery are offered to match your schedule and budget. We supply real-time cargo tracking service so you can monitor shipment status anytime.

Flexible Payment

We support a wide range of secure international payment terms such as T/T, L/C, Western Union and other mainstream cross-border settlement methods to reduce your cross-border transaction risks.

After-Sales Support

Our professional after-sales team offers timely technical and business support all year round. We maintain steady long-term stable supply capacity to fully back up your continuous market sales and project demands.

FAQ

01 Question: Can you produce based on customers’ drawings or physical samples?

Answer: Absolutely yes. We accept technical drawings in all mainstream file formats as well as actual physical samples. Before formal production, our engineering team will provide a full professional DFM feasibility evaluation for your reference.

02 Question: How long is the production lead time for custom orders?

Answer: Sample lead time: 3–7 working days. Custom mold lead time: 5–10 working days (we will confirm the cycle separately with you for complex molds). Mass production lead time: 7–20 working days, depending on product structure complexity and order quantity.

03 Question: What’s your minimum order quantity for custom products?

Answer: We provide flexible MOQ solutions for all customized items. We will try our best to set a low minimum order volume to support your small-batch trial orders, meanwhile we can handle stable mass production to satisfy your long-term bulk demands.

04 Question: What customization services can you provide?

Answer: We support comprehensive one-stop customization, including product size, shape, appearance, precision tolerance, surface treatment, hole grooving, bending, cutting and adjustable high-temperature resistant parameters. Custom engraved LOGO and exclusive customized packaging are also available as extra personalized options upon request.

05 Question: Do you accept third-party inspection of finished products?

Answer: Yes, we fully cooperate with all mainstream authorized third-party testing institutions. Well-known organizations such as SGS, BV and other internationally recognized inspection bodies are all acceptable. We can supply complete official inspection reports and material certification documents as you require.

06 Question: Can you customize raw material options for products?

Answer: Sure. We can select and match appropriate raw materials according to your application scenarios, working conditions and performance requirements, including alumina, zirconia, quartz, silicone and other special engineering materials, and adjust related performance parameters to meet your usage standards.
